Mapping tool from injection simulation

Easy mapping of injection simulation results associated with the original mesh to the mesh for structural simulations.

Request a service / solution

Easy mapping of injection simulation results associated with the original mesh to the mesh for structural simulations. Subsequently, the decomposition of the orientation tensor into major flow directions and the relative representation of the flow in these directions is performed. An integral part is the linking of this information to the material map.
